Automatic X-ray Film Processor

Feature

• 2.4 inch LCD screen, can display developer, fixer, drying temperature and processor speed
• With Intel chip, it has the function of failure analysis and troubleshooting.

Specifications

• Film size? *Standard film: single piece?76×152?356×432??mm??3?×6??14?×17??
• film width: 17’’, length have no limited.
• Tank volume: Developer 11L, fixer 11L, water 11L
• Processor speed: 90s-360s adjustable
• Develop time: 20s-90s choice
• Develop temp: 20?-42? adjustable
• Drying temp: 40?-60? adjustable
• Developing Capability: 160films/hour (14’’x17’’), 180films/hour(10’’x12’’)
• Supplement fluid methods: automatic or manual
• Supplement fluid volume: setting between 20ml-400ml
• Water wash control: Control by magnetic valve automatically, inflow water while film in
• Film in mode: Photoelectric reaction
• Developing sequence: Developing, washing, fixing, washing, drying
• Stand by: 24hours
• Noise: ?55
• Size: L*W*H 1180x630x1100mm
• Net Weight:115KGS, Gross Weight:130KGS
